12/24V/48V 60W-400W Intelligent Dimmable LEDSwitching Power Supply Driver

12/24V/48V 60W-400W

Intelligent Dimmable LEDSwitching Power Supply Driver

High-Safety

Multiple Safety Protections andAnti-Interference

Integrated with input overvoltage and overcurrentprotection, output overload and short circuitprotection, and whole machine over temperatureprotection; the dimming signal terminal is equippedwith an EMC anti-interference circuit to resist surgesand static electricity, avoiding dimming flicker andcolor temperature jump caused by power gridfluctuations and electromagnetic interference.

High-Efficiency

Long-Life Structure

& High-Efficiency Heat Dissipation

Fast heat dissipation aluminum alloy shell +high-temperature resistant pure copper transformerwith natural convection heat dissipation. The shelltemperature rise is <50°C under full-load conditions,MTBF50,000 hours. The core chip adopts anindustrial-grade solution to adapt to long-termcontinuous operation.

Energy-Saving Design

High PF & High Efficiency

High PF & High Efficiency Energy-Saving DesignPower factor PF>0.9 and conversion efficiency>90%for the full power range, complying withenergy-saving lighting standards, reducing powergrid loss and equipment heating, and adapting to24-hour long-term operation conditions.
